DEYE 8kW Hybrid Inverter SUN-8K-SGO5LP1-EU-SM2 | Single Phase

Video

DEYE 8kW Hybrid Inverter SUN-8K-SGO5LP1-EU-SM2 | Single Phase

Name: DEYE 8kW Hybrid Inverter SUN-8K-SGO5LP1-EU-SM2 | Single Phase
Brand: Deye
SKU: SUN-8K-SGO5LP1-EU-SM2
Price: 180000 KES
Availability: OutOfStock

Out-of-Stock

KES180,000.00

Tax included

☀️ 8kW Hybrid. 16kW Solar. 190A. AC Coupling. Gen Port. IP65.

8kW hybrid, 16kW solar, 190A, AC coupling, gen port, IP65 — KES 175,000.

☀️ 8kW Output

⚡ 16kW Solar

🔋 190A Battery

🌧️ IP65

8kW
AC Output

16kW
Solar (2 MPPT)

150~425V
MPPT Range

97.6%
Max Efficiency

⚡ 190A + AC Coupling — Retrofit-Ready 190A charge & discharge. AC coupling — retrofit an existing system without rewiring.	☀️ 16kW Solar — Dual MPPT 16kW panels on an 8kW inverter — 200% DC. Dual MPPT (150~425V).
📶 Gen Port + ×16 Parallel Scale Dedicated gen input. ×16 parallel. <30dB. Colour touch LCD.	🌧️ IP65 + WiFi/BT/4G Monitoring IP65 weatherproof. WiFi/BT/4G/RS485/CAN. BMS auto-adapt. 97.6% eff. 5yr.

📦 In the Box: SUN-8K-SG05LP1-EU-SM2 ▸ Mounting Hardware ▸ Manual | 8kW | 48V LV | 5yr

Variants

Vestwoods 6kW Hybrid Inverter (VW6KSLES) | 6000W Single Phase | 9000W Solar Input

GoodWe STS Series Static Transfer Switch | STS200-80-10

GoodWe 20kW Three-Phase Hybrid Inverter GW20K-ET-L-G10 | 48V Low Voltage Battery Compatible

GoodWe 15kW Three-Phase Hybrid Inverter GW15K-ET-L-G10 | 48V Low Voltage Battery Compatible

GoodWe 50kW Three-Phase Hybrid Inverter GW50K-ET-10 | High Voltage Commercial Solar

GoodWe 10kW ES Uniq Hybrid Inverter LV GW10K-ES-C10 | Single Phase

+10

GoodWe 12kW ES Uniq Hybrid Inverter LV GW12K-ES-C10 | Single Phase

GoodWe 6kW Hybrid Solar Inverter (GW6000-ES-C10) | 6000W Single Phase | 48V Battery Compatible

GoodWe 5kW Hybrid Solar Inverter (GW5000-ES-C10) | 5000W Single Phase | 48V Battery Compatible

GoodWe 8kW ES Uniq Hybrid Inverter LV GW8000-ES-C10 | Single Phase

Bluetti AC300 3000W Modular Inverter | 6000W Surge | Expandable LiFePO4 Home Backup

Bluetti B300K 2764Wh Expansion Battery | LiFePO4 Battery Module for AC200L, AC300, AC500

GoodWe 6kW Solar Inverter (GW6k-EO-G20) | Single Phase, 48V, Dual MPPT & IP66

DEYE 5kW Hybrid Inverter SUN-5KSG04LP1-EU-SM2 | Single Phase

DEYE 10kW Hybrid Inverter SUN-10K-SG02 LP1-EU-AM3 | Single Phase

Description

DEYE 8kW Hybrid Inverter SUN-8K-SGO5LP1-EU-SM2 | Single Phase

Deye SUN-8K-SG05LP1-EU-SM2 8kW Single-Phase Low-Voltage Hybrid Inverter

Maximize your residential energy independence with the updated Deye SUN-8K-SG05LP1-EU-SM2. This high-efficiency single-phase low-voltage hybrid inverter is engineered for safe 48V battery operation, offering robust power handling with an increased max charging and discharging current of 190A. Featuring dual MPPT trackers, intelligent 6-period time-of-use scheduling, AC coupling capabilities, and parallel expansion support for up to 16 units, it delivers seamless grid-tied and off-grid performance.

Why Choose the Deye 8kW Single-Phase Hybrid Inverter?

⚡ Dual MPPT & High PV Access

Equipped with 2 independent MPP trackers (2+2 strings) supporting a wide 150V–425V MPPT voltage range and high short-circuit tolerances.

🔋 Safe 48V Architecture

Designed for secure low-voltage lead-acid or lithium-ion batteries with automatic BMS self-adaptation and up to 190A current throughput.

🔄 Flexible Parallel Expansion

Supports parallel operation for up to 16 units in both on-grid and off-grid setups, allowing multiple systems to scale easily.

🛡️ Rugged Weatherproofing

Housed in an IP65-rated enclosure with intelligent air cooling, built to withstand extreme operating temperatures from -40°C to +60°C.

Advanced Features & Functions

Time-of-Use Control: Features 6 programmable time periods for versatile battery charging and discharging schedules.
AC Coupling Retrofit: Easily integrates with existing solar configurations to upgrade them into comprehensive energy storage setups.
Generator Integration: Fully supports storing energy sourced directly from backup diesel generators.
Comprehensive Protections: Integrated with Type II surge protection (DC/AC), AFCI (optional), anti-islanding, DC switch, and residual current monitoring.
Smart Interfaces: Features a colorful touch LCD display alongside RS485, RS232, CAN, and optional Wi-Fi/GPRS/485 communication.

Technical Specifications

Specification	Deye SUN-8K-SG05LP1-EU-SM2 Details
Rated AC Output Active Power	8,000W (Max Apparent Power: 8,800VA)
Battery Voltage Range	40V – 60V (Lead-acid or Lithium-ion)
Max. Charge / Discharge Current	190A / 190A
Max. PV Access & Input Power	15,200W Max Access Power / 12,160W Max Input Power
MPPT Trackers / Voltage Range	2 Trackers (2+2 Strings) \| MPPT Range: 150V – 425V
Max. & Euro Efficiency	97.6% Max Efficiency / 96.5% Euro Efficiency
Enclosure & Cooling	IP65 Rated, Intelligent Air Cooling, Noise <45 dB
Dimensions & Weight	366 × 589.5 × 237 mm (Excluding connectors/brackets) \| 26.8 kg

SUN-8K-SGO5LP1-EU-SM2

Product Details

Battery Type: Can do Both Li-Ion and Lead-acid
AC Outlets: 8000watts
Solar Charge Input: 16000watts
Weight: 27Kgs
Dimensions: 366mm×589.5mm×237mm (Excluding Connectors and Brackets)
Warranty: 5 Years
General: Please see Datasheet Attached Below

Brand

Reference SUN-8K-SGO5LP1-EU-SM2

MPN SUN-8K-SGO5LP1-EU-SM2

Attachments

Deye Inverter Datasheet SUN_7-10kW

Download (491.8KB)
