Deye 15kW Three Phase Hybrid Inverter (SUN-15K-SG05LP3-EU-SM2) | Dong Solar

Deye 15kW 3-Phase Hybrid Inverter (SUN-15K-SG05LP3-EU-SM2)

Deye 15kW Three Phase Hybrid Inverter (SUN-15K-SG05LP3-EU-SM2) | Dong Solar

Name: Deye 15kW Three Phase Hybrid Inverter (SUN-15K-SG05LP3-EU-SM2) | Dong Solar
Brand: Deye
SKU: SUN-15K-SG05LP3-EU-SM2
Price: 320000 KES
Availability: InStock

Last items in stock

KES320,000.00

Tax included

☀️ 15kW 3-Phase. 24kW Solar. 280A. AC Coupling. Gen Port. IP65.

15kW 3-Phase Low Voltage hybrid, 24kW solar input, 280A charge/discharge, AC coupling, gen port, IP65.

☀️ 15kW 3-Phase

⚡ 24kW Solar

🔋 280A Battery

🌧️ IP65

15kW
3-Phase AC Output

24kW
Max PV Input (2 MPPT)

280A
Max Charge/Discharge

48V
Low Voltage Battery

⚡ 280A + 48V Low Voltage Battery 280A max charge & discharge current. Transformer-isolated 48V LV design for enhanced safety.	☀️ 24kW Solar Input — 160-650V MPPT Supports up to 24,000W PV input across 2 MPPTs. 100% unbalanced 3-phase output capability.
📶 Gen Input + ×10 Parallel Scaling Store energy from diesel generators. Connect up to 10 units in parallel for on/off-grid operation.	🌧️ IP65 Enclosure + Smart Monitoring IP65 outdoor rated. Color LCD touchscreen, WiFi/RS485/CAN interface, 6-period battery scheduling.

📦 In the Box: SUN-15K-SG05LP3-EU-SM2 ▸ Mounting Bracket & Kit ▸ User Manual | 15kW 3-Phase | 48V LV | 5yr

Description

Deye 15kW Three Phase Hybrid Inverter (SUN-15K-SG05LP3-EU-SM2) | Dong Solar

Deye SUN-15K-SG05LP3-EU-SM2 15kW Three-Phase Low-Voltage Hybrid Inverter

Scale up your commercial or high-power residential solar storage with the Deye SUN-15K-SG05LP3-EU-SM2. This advanced three-phase low-voltage hybrid inverter combines a heavy-duty 15kW output with an impressive 280A charge and discharge current profile. Engineered with 100% unbalanced phase capability, dual MPPT channels, transformer isolation design for the battery circuit, and parallel scalability up to 10 units, it provides absolute reliability for demanding grid-tied and off-grid environments.

Why Choose the Deye 15kW Three-Phase Hybrid Inverter?

⚡ Dual MPPT & High PV Capacity

Features 2 robust MPP trackers supporting up to 30,000W of maximum PV access power to handle large array configurations easily.

🔋 48V Low-Voltage & 280A Current

Designed for safe 48V lead-acid or lithium-ion batteries with automatic BMS communication, dual battery inputs, and a robust 280A charging/discharging limit.

🔄 100% Unbalanced Three-Phase Output

Supports completely unbalanced load output per phase, allowing each phase to deliver up to 50% of the rated power output.

🛡️ Scalable & Weatherproof

Enables parallel expansion of up to 10 units housed inside a rugged IP65-rated enclosure built for outdoor deployments up to 3000m altitude.

Advanced Features & Functions

Flexible Multi-String Inputs: Incorporates dual MPP trackers configured across multiple string connections (2+2 strings) with high short-circuit tolerance.
Time-of-Use Scheduling: Offers 6 distinct programmable time slots to optimize battery charging and discharging cycles.
AC Coupling Compatibility: Easily retrofits into existing grid-tied photovoltaic arrays to transform them into storage systems.
Diesel Generator Support: Direct compatibility for storing surplus energy or powering loads directly from backup generators.
Comprehensive Connectivity: Includes RS485, CAN, and built-in WiFi communication interfaces alongside an LCD touch display.

Technical Specifications

Specification	Deye SUN-15K-SG05LP3-EU-SM2 Details
Rated AC Output Active Power	15,000W (Max Apparent Power: 16,500VA)
Battery Voltage Range	40V – 60V (Lead-acid or Lithium-ion)
Max. Charge / Discharge Current	280A / 280A
Max. PV Input Power	24,000W (Max PV Access Power: 30,000W)
MPPT Trackers / Voltage Range	2 Trackers (2+2 Strings) \| Range: 160V – 650V
Max. & Euro Efficiency	97.6% Max Efficiency / 97.0% Euro Efficiency
Enclosure & Cooling	IP65 Rated, Intelligent Air Cooling, Noise <60 dB
Dimensions & Weight	456 × 750 × 268.5 mm \| 51.9 kg

Deye 15kW Three Phase Hybrid Inverter (SUN-15K-SG05LP3-EU-SM2) | Dong Solar

Product Details

AC Outlets: 15kW
Weight: 52kgs
Dimensions: 456mm×750mm×268.5mm (Excluding Connectors and Brackets)
General: Please see Datasheet Attached Below
Maximum PV Array Open Circuit Voltage: 800VDC
PV Array MPPT Voltage Range (Typ.): 160V-650V
Maximum PV Array Power: 24kW

Brand

Reference SUN-15K-SG05LP3-EU-SM2

In stock 1 Item

MPN SUN-15K-SG05LP3-EU-SM2

Attachments

Deye Datashet SUN-15K-SG05LP3-EU-SM2

Download (212.17KB)
