DEYE 5kW Hybrid Inverter SUN-5KSG04LP1-EU-SM2 | Single Phase

DEYE 5kW Hybrid Inverter SUN-5KSG04LP1-EU-SM2 | Single Phase

Name: DEYE 5kW Hybrid Inverter SUN-5KSG04LP1-EU-SM2 | Single Phase
Brand: Deye
SKU: SUN-5KSG04LP1-EU-SM2
Price: 120000 KES
Availability: InStock

Last items in stock

KES120,000.00

Tax included

☀️ 5kW Single-Phase Hybrid Solar Inverter

High-efficiency energy storage with dual MPPT, generator support, and flexible scaling.

☀️ 5kW AC Output

⚡ 8kW Max PV

🔋 120A Charge/Discharge

🌧️ IP65 Rated

<4ms
UPS Changeover

500V
Max PV Voltage

150~425V
MPPT Voltage Range

97.6%
Max Efficiency

⚡ Rapid UPS Switching & AC Coupling Ultra-fast <4ms UPS transfer delay. Supports Lead-Acid/Li-ion (40-60V) with self-adapting BMS & AC coupling retrofit.	☀️ Dual MPPT PV Input 10,000W max PV access. Features 2 MPP trackers (1+1 strings) with 18A+18A operating current and 125V start-up.
📶 Generator Port & Scalability Stores energy from diesel generators. Connect up to 16 units in parallel for grid or off-grid expansion.	🌧️ Protection & Smart Display Integrated Type II DC/AC surge protection with natural cooling (<45dB). Colour touch LCD display with Wi-Fi/RS485/CAN.

📦 In the Box: SUN-5K-SG04LP1-EU-SM2 Inverter ▸ Mounting Brackets ▸ User Manual | 19 kg | 5/10yr Warranty

Variants

Vestwoods 6kW Hybrid Inverter (VW6KSLES) | 6000W Single Phase | 9000W Solar Input

GoodWe STS Series Static Transfer Switch | STS200-80-10

GoodWe 20kW Three-Phase Hybrid Inverter GW20K-ET-L-G10 | 48V Low Voltage Battery Compatible

GoodWe 15kW Three-Phase Hybrid Inverter GW15K-ET-L-G10 | 48V Low Voltage Battery Compatible

GoodWe 50kW Three-Phase Hybrid Inverter GW50K-ET-10 | High Voltage Commercial Solar

GoodWe 10kW ES Uniq Hybrid Inverter LV GW10K-ES-C10 | Single Phase

+10

GoodWe 12kW ES Uniq Hybrid Inverter LV GW12K-ES-C10 | Single Phase

GoodWe 6kW Hybrid Solar Inverter (GW6000-ES-C10) | 6000W Single Phase | 48V Battery Compatible

GoodWe 5kW Hybrid Solar Inverter (GW5000-ES-C10) | 5000W Single Phase | 48V Battery Compatible

GoodWe 8kW ES Uniq Hybrid Inverter LV GW8000-ES-C10 | Single Phase

Bluetti AC300 3000W Modular Inverter | 6000W Surge | Expandable LiFePO4 Home Backup

Bluetti B300K 2764Wh Expansion Battery | LiFePO4 Battery Module for AC200L, AC300, AC500

GoodWe 6kW Solar Inverter (GW6k-EO-G20) | Single Phase, 48V, Dual MPPT & IP66

DEYE 10kW Hybrid Inverter SUN-10K-SG02 LP1-EU-AM3 | Single Phase

DEYE 8kW Hybrid Inverter SUN-8K-SGO5LP1-EU-SM2 | Single Phase

Description

DEYE 5kW Hybrid Inverter SUN-5KSG04LP1-EU-SM2 | Single Phase

Deye SUN-5K-SG04LP1-EU-SM2 5kW Single-Phase Hybrid Inverter

Optimize your residential energy independence with the Deye SUN-5K-SG04LP1-EU-SM2. This advanced low-voltage hybrid inverter integrates high-efficiency power conversion, an upgraded 120A charge/discharge current, and flexible on/off-grid operation. Equipped with dual MPPT trackers, a colorful touch-screen LCD, and support for parallel scaling up to 16 units, it delivers robust backup protection and intelligent power management.

Why Choose the Deye 5kW Hybrid Inverter?

⚡ High Efficiency & PV Capacity

Delivers up to 97.6% max efficiency with support for up to 10,000W max PV access power to maximize your solar harvesting capability.

🔋 Upgraded 120A Battery Performance

Supports 40–60V lead-acid and lithium-ion batteries featuring BMS self-adaptation and a powerful 120A maximum charging and discharging current.

🔄 Multi-Unit Parallel Operation

Supports a maximum of 16 units in parallel for both on-grid and off-grid configurations, allowing your system capacity to scale effortlessly.

🛡️ Rugged IP65 & Natural Cooling

Built with an IP65 ingress protection rating and fanless natural cooling to ensure quiet, dependable operation in harsh environments.

Advanced Features & Functions

Dual MPP Trackers: Features 2 trackers with 1+1 strings to handle complex roof orientations and optimize overall energy yield.
Intelligent Time-of-Use Control: Programmable with 6 distinct time periods for flexible battery charging and discharging schedules.
AC Coupling Retrofit: Seamlessly retrofits existing grid-tied solar systems into full storage setups.
Diesel Generator Support: Fully compatible with storing or supplying energy sourced from backup diesel generators.
Interactive Display & Comms: Equipped with a colorful touch LCD screen alongside WiFi, RS485, and CAN communication interfaces.

Technical Specifications

Specification	Deye SUN-5K-SG04LP1-EU-SM2 Details
Rated AC Output Power	5000W (Max Apparent Power: 5500VA)
Battery Voltage Range	40V – 60V (Lead-acid or Lithium-ion)
Max. Charge / Discharge Current	120A / 120A
Max. PV Input Power	5760W (Max Access Power: 10,000W)
MPPT Trackers / Range	2 Trackers (1+1 Strings) \| Range: 150V – 425V
Max. & Euro Efficiency	97.6% Max / 96.5% Euro Efficiency
Enclosure & Cooling	IP65 Rated, Natural Cooling, Noise <45 dB
Dimensions & Weight	376 × 470 × 241.5 mm \| 19 kg

DEYE 5kW Hybrid Inverter SUN-5KSG04LP1-EU-SM2 | Single Phase

Product Details

Battery Type: Can do Both Li-Ion and Lead-acid
AC Outlets: 5000watts
Solar Charge Input: 8000watts
Weight: 19Kgs
Dimensions: 376mm × 470mm × 241.5mm (Excluding Connectors and Brackets)
Warranty: 5 Years
UPS Switching time: Less than 4ms
General: Please see Datasheet Attached Below

Brand

Reference SUN-5KSG04LP1-EU-SM2

In stock 1 Item

MPN SUN-5KSG04LP1-EU-SM2

Attachments

Datasheet SUN-5KSG04LP1-EU-SM2

Download (194.17KB)

Reviews (0)

No reviews

Comments (0)

No customer reviews for the moment.
