SRNE 10kW Hybrid Solar Inverter Single Phase | ASP48100S200-H

SRNE 10kW Hybrid Solar Inverter Single Phase | ASP48100S200-H

Name: SRNE 10kW Hybrid Solar Inverter Single Phase | ASP48100S200-H
Brand: SRNE
SKU: ASP48100S200-H
Price: 125000 KES
Availability: InStock

Last items in stock

KES125,000.00

Tax included

☀️ 10kW 48V Hybrid Solar Inverter

High-output pure sine wave inverter with dual MPPT controllers, 200A solar charging, and split-phase support.

☀️ 10,000W AC Output

⚡ 11,000W Max PV

🔋 200A MPPT

⚡ Dual MPPT

<10ms
UPS Switchover

500V
Max PV Voltage

120~450V
MPPT Voltage Range

15,000W
Peak Surge Power

⚡ Ultra-High 200A MPPT Charging Dual MPPT trackers delivering up to 200A solar charge current to 48V Li-ion and Lead-Acid battery systems.	☀️ 11kW Dual Tracker PV Input Supports up to 11,000W total array capacity across two independent MPPT inputs (22A+22A max input current).
📶 Generator Auto-Start & Parallel Scale Dry contact dry-start relay for backup generators. Supports parallel connection up to 6 units for large system expansion.	🌧️ Split-Phase / Single-Phase Flexible Output Configurable 120/240V split-phase or 230V output. Complete protection with RS485/CAN/Wi-Fi smart communication.

📦 In the Box: SRNE ASP48100S200-H All-In-One Inverter ▸ Wall Mounting Bracket ▸ User Manual | 48V Low Voltage System

Variants

HINEN PS1800 Portable Power Station | 1800W 1229Wh

MARSTEK S2000F Portable Power Station | 2000W 2042Wh

ECOFLOW DELTA 3 Portable Power Station | 1800W 1024Wh

BLUETTI AC70P Portable Power Station | 1000W 864Wh

BLUETTI Premium 30 V2 Portable Power Station | 600W 320Wh

BLUETTI AC180P Portable Power Station | 1800W 1440Wh

+16

EcoFlow RIVER 3 Plus Portable Power Station | 600W 268Wh

EcoFlow RIVER 3 Portable Power Station | 300W 245Wh

REOMAX portable Power Station | 500W 1000Wh

BLUETTI AC200P L Portable Power Station 2400W 2304Wh – High-Capacity Solar Generator & Home Backup

BLUETTI EB3A Portable Power Station | 600W 268Wh

BLUETTI Premium 100 V2 Portable Power Station | 2000W 1024Wh

SOLARTHON portable Power Station eBean500 | 500W 2000Wh

BLUETTI AC2P Portable Power Station | 300W 230Wh

BLUETTI AC50P Portable Power Station | 700W 504Wh

REOMAX portable Power Station | 100W 2000Wh

VESTWOODS portable Power Station | 500W 1000Wh

VESTWOODS portable Power Station | 1000W 2000Wh

BLUETTI Premium 200 V2 Portable Power Station | 2700W 2074Wh

HINEN PS3000 Portable Power Station | 3000W 2560Wh

SOLARTHON portable Power Station | 200W 1000Wh

Description

SRNE 10kW Hybrid Solar Inverter Single Phase | ASP48100S200-H

SRNE ASP48100S200-H 10kW Single-Phase Hybrid Solar Inverter

Scale up your energy independence with the official datasheet-verified SRNE ASP48100S200-H. This high-output 48V hybrid solar inverter delivers a continuous rated power output of 10,000W and a peak power capacity of 15,000VA. Featuring dual independent MPPT trackers supporting up to 11,000W of total PV array input (5,500W + 5,500W with 22A + 22A max input current), an ultra-fast 200A max MPPT charging current, parallel scalability up to 6 units (single or three-phase configurations), and smart time-slot tariff optimization, it provides a robust hub for demanding residential or commercial systems backed by a 2-year manufacturer warranty.

Why Choose the SRNE ASP48100S200-H?

⚡ Dual MPPT High PV Input

Equipped with 2 independent MPPT trackers (5,500W each) totaling 11,000W of PV array capacity, handling up to 500Vdc open-circuit voltage per tracker.

🔋 Ultra-Fast 200A Charging

Delivers up to 200A max solar charging current and 120A max mains/generator charging current to quickly replenish large 48V battery banks.

🔄 Heavy Motor Support

Engineered to drive heavy loads effortlessly with a 6HP motor starting capacity, pure sine wave output, and a fast 10ms typical switch time.

📈 Scalable Architecture

Supports parallel expansion from 1 to 6 units, allowing single-phase or three-phase output configurations for larger commercial needs.

Advanced Features & Functions

Flexible Battery Integration: Compatible with Li-ion, Lead-Acid, and User-Defined 48V battery systems featuring exclusive BMS dual activation.
Comprehensive Protections: Built-in hardware and software safeguards covering PV input current limiting, over-voltage, reverse current, grid protections, and thermal derating.
Remote Monitoring Connectivity: Includes embedded RS485, CAN, USB, and dry contact interfaces, with optional external Wi-Fi and GPRS modules.
Robust Build: Indoor-rated (IP20) chassis utilizing quiet internal fan cooling (<60dB) and compact dimensions.

Technical Specifications

Specification	SRNE ASP48100S200-H Datasheet Details
Rated Output Power & Peak	10,000W \| Max. Peak Power: 15,000VA (230Vac Single-Phase)
Battery Type & Voltage Range	Li-ion / Lead-Acid / User Defined \| 48Vdc Rated (40~60Vdc Range)
Charging Current Options	Max. MPPT Charging: 200A \| Max. Mains/Gen: 120A \| Max. Hybrid: 200A
Solar Input Specs	Max. PV Array Power: 5,500W + 5,500W \| Max Input Current: 22A + 22A
MPPT Range & Efficiency	125~425Vdc (Max Voc: 500Vdc + 500Vdc) \| MPPT Efficiency: 99.9%
System Scalability & Bypass	Parallel 1~6 units (Single/Three-Phase) \| Mains Input: 90~275Vac, 63A Bypass
Operating Environment & Protection	-10~55°C (>45°C derated) \| IP20 Indoor Only, Noise <60dB
Certifications & Warranty	IEC62109-1/-2, EN61000-6-1/-3, FCC Class B, RoHS \| 2-Year Warranty
Dimensions & Weight	620 × 445 × 130 mm (2.03 × 1.46 × 0.43 ft) \| 27 kg (59.52 lbs)

SRNE 10kW Hybrid Solar Inverter Single Phase | ASP48100S200-H

Product Details

Battery Type: Can use Lithium or Lead Acid
AC Outlets: 10,000w Surge 15,000w
Surge Power: 15,000w
Solar Charge Input: 2 * 5500Watts 500VDC + 500VDC
Weight: 27Kgs
Dimensions: 620*445*130mm(2.03*1.46*0.43ft)
Warranty: 2 Years
General: Please see Datasheet Attached Below

Brand

Reference ASP48100S200-H

In stock 2 Items

MPN ASP48100S200-H

Attachments

SRNE ASP_8_10Kw Inverter

Download (1.68MB)
