3.6kW InfiniSolar HP800-3624 Off-Grid Solar Inverter 24V

3.6kW InfiniSolar HP800-3624 Hybrid Solar Inverter 24V

Name: 3.6kW InfiniSolar HP800-3624 Hybrid Solar Inverter 24V
Brand: INFINISOLAR
SKU: HP800-3624
Price: 30000 KES
Availability: InStock

Last items in stock

KES30,000.00

Tax included

⚡ 3.6kW Pure Sine | ☀️ 4kW PV | 🔋 100A MPPT Charging | 🚀 6000VA Peak | ⏱️ 10ms UPS

InfiniSolar HP800-3624 pure sine wave inverter with 100A MPPT, 10ms UPS transfer, and battery-free operation.

☀️ 4000W PV Input

🔋 100A MPPT

⏱️ 10ms UPS Transfer

⚡ Peak Output: 6000VA

10ms
UPS Switchover

3600W
Rated Output Power

400V
Max PV Array Voltage

7.8 kg
Compact Design

⏱️ Instant 10ms UPS Backup Power Ultra-fast 10ms transfer time ensures seamless switchover during outages, keeping sensitive electronics, PCs, and appliances online without rebooting.	☀️ High-PV Array & Battery-Free Running Supports up to 4,000W solar input with a 30–320V MPPT range. Capable of powering daytime AC loads directly from solar without a connected battery.
🔌 Smart Dual AC Output \| Peak Output: 6000VA Manages primary and secondary load outputs independently. Handles 6,000W peak surge power for starting motor-driven appliances safely.	📶 CAN/RS485 Lithium BMS Communication Equipped with dedicated CAN and RS485 communication ports for automated handshake with 24V LiFePO4 battery BMS systems, plus Wi-Fi monitoring support.

📦 In the Box: InfiniSolar HP800-3624 3.6kW 24V Inverter ▸ Anti-Dust Filter Kit ▸ User Manual & Wall Brackets

Variants

3.2kW InfiniSolar VP800II Off-Grid Solar Inverter 24V | Pure Sine Wave MPPT Inverter/Charger

6kW InfiniSolar HP800-6048 Off-Grid Solar Inverter 48V

Description

3.6kW InfiniSolar HP800-3624 Off-Grid Solar Inverter 24V

Product Details

Surge Power: 6000VA
AC Charging Input: 230VAC 50Hz / 60Hz (Auto sensing)
Weight: Net Weight: 7.8kg Gross Weight: 9.3kg
Dimensions: 318mm * 454mm* 123mm
Package Dim 544.5mm * 200mm * 410mm
Certifications: CE-EMC+LVD(EN6100-6-3, EN6100-6-1+EN IEC62109-1, EN IEC62109-2)
Warranty: 1 Year
UPS Switching time: UPS Transfer Time: 10ms Typical
Watts: 3600VA/3600W
General: High Frequency Solar Inverter
Please see Datasheet Attached Below
Default Battery System Voltage: 24VDC
Maximum PV Array Open Circuit Voltage: 400VDC
PV Array MPPT Voltage Range (Typ.): 30~320VDC
Standby Power Consumption: 2W
Maximum Solar Charge Current: 100A

Brand

Reference HP800-3624

In stock 1 Item

MPN HP800-3624

Attachments

HP800 Inverters Datasheet

Download (484.79KB)
